Features
- IP-67 Ingress protection.
- Welded body with sides, top and bottom closed in 1.2 thk folded CRCA sheet.
- Front single door in 1.2 thk CRCA sheet. With metal hinges, cam locks.
- Polyethylene gasket on door and polyurethane foam on gland plate, both are fire retardant.
- M-4 tapped Z angles inside for DIN rail mountings (No component mounting plate inside).
- As side walls are not removable, inter panel separator is not required here.
- Gland plate optional at bottom in 2.00 thk CRCA.
- These types of enclosures are not suitable to join together, however if needed we can join them.
Standard Sizes
| Width | Depth | Height |
|---|---|---|
| 100mm-600mm ( in pith of 50mm ) | 80mm-200mm ( in pith of 50mm ) | 100mm-600mm ( in pith of 50mm ) |
There is access from front only a sides and top are closed.
